Feature:
LGA1155 socket for 3rd generation Intel Core processor-based platform and 2nd Generation Core i7/ i5/ i3/ Pentium / Celeron Processors
Intel Z77 Express Chipset
SupremeFX III - Supreme Sound
GameFirst / Intel Gb LAN – Frag Without Lag
mPCIe Combo – Give Your PC A Power Up!
NIVIDIA SLI / AMD CrossFireX Technology Support
LucidLogix Virtu MVP - Up to 60% Hybrid Graphics Boost
Spesifikasi:
CPU | Intel Socket 1155 for 3rd/2nd Generation Processors Supports Intel 22 nm CPU Supports Intel 32 nm CPU Supports Intel Turbo Boost Technology 2 * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types. |
Chipset | Intel Z77 |
Memori | 4 x DIMM, Max. 32GB, DDR3 MHz Non-ECC, Un-buffered Memory Dual Channel Memory Architecture Supports Intel Extreme Memory Profile (XMP) * Refer to asus or user manual for the Memory QVL (Qualified Vendors Lists). * Hyper DIMM support is subject to the physical characteristics of individual CPUs. |
Grafis | Integrated Graphics Processor Dukungan output Multi-VGA : HDMI/DisplayPort port - Mendukung HDMI dengan resolusi maks. 1920 x 1200 @ 60 Hz - Supports DisplayPort with max. resolution 2560 x 1600 @ 60 Hz Supports Intel HD Graphics, InTru 3D, Quick Sync Video, Clear Video HD Technology, Insider |
Dukungan Multi-GPU | Supports NVIDIA SLI Technology Supports AMD CrossFireX Technology Supports LucidLogix Virtu MVP Technology |
Slot Ekspansi | 2 x PCIe 3.0/2.0 x16 (x16 or dual x8, red) 1 x PCIe 2.0 x4 (black) 1 x mini-PCIe 2.0 x1 |
Storage | Intel Z77 chipset : 2 x SATA 6Gb/s port(s), red 2 x SATA 3Gb/s port(s), black 1 x eSATA 3Gb/s port(s), red 1 x mini-SATA 3Gb/s port(s), black Support Raid 0, 1, 5, 10 Supports Intel Smart Response Technology, Intel Rapid Start Technology, Intel Smart Connect Technology ASMedia PCIe SATA controller : 2 x SATA 6Gb/s port(s), red |
LAN | Intel, 1 x Gigabit LAN Controller(s) |
Audio | SupremeFX III built-in 8-Channel High Definition Audio CODEC - Output Signal-to-Noise Ratio (A-Weighted): 110 dB - Output THD+N at 1kHz: 95 dB - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking Audio Feature : - SupremeFX Shielding™ Technology - 1500 uF Audio Power Capacitor - Gold-plated jacks - X-Fi Xtreme Fidelity - EAX® Advanced™ HD 5.0 - THX TruStudio PRO - Creative ALchemy - Blu-ray audio layer Content Protection - Optical S/PDIF out port(s) at back panel |
Port USB | Intel Z77 chipset : 4 x USB 3.0 port(s) (2 at back panel, blue, 2 at mid-board) Intel Z77 chipset : 8 x USB 2.0 port(s) (4 at back panel, black+white, 4 at mid-board) ASMedia USB 3.0 controller : 2 x USB 3.0 port(s) (2 at back panel, blue) |
Fitur-Fitur Overclocking | mPCIe Combo (mPCIe/mSATA combo card) ROG Connect : - RC Diagram - RC Remote - RC Poster - GPU TweakIt Extreme Engine Digi+ II : - 8 -phase CPU power design + 4 -phase iGPU power design - 2 -phase QPI/DRAM power design ProbeIt UEFI BIOS features : - ROG BIOS Print - GPU.DIMM Post GameFirst iROG Extreme Tweaker Loadline Calibration USB BIOS Flashback Overclocking Protection : - ASUS C.P.R.(CPU Parameter Recall) |
Fitur-Fitur Khusus | ASUS Hybrid Processor - TurboV EVO : - CPU Level Up ASUS EPU : - EPU ASUS Exclusive Features : - AI Suite II - Ai Charger+ - USB 3.0 Boost - Disk Unlocker ASUS EZ DIY : - ASUS O.C. Profile - ASUS CrashFree BIOS 3 - ASUS EZ Flash 2 ASUS Q-Design : - ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED) - ASUS Q-Slot - ASUS Q-DIMM - ASUS Q-Connector |
Port I/O Belakang | 1 x DisplayPort 1 x HDMI 1 x eSATA 3Gb/s 1 x LAN (RJ45) port(s) 4 x USB 3.0 4 x USB 2.0 (one port can be switched to ROG Connect) 1 x Optical S/PDIF out 6 x Audio jack(s) 1 x Clear CMOS button(s) 1 x ROG Connect On/ Off switch(es) |
I/O Internal | 1 x USB 3.0 connector(s) support(s) additional 2 USB 3.0 port(s) 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) 4 x SATA 6Gb/s connector(s) 2 x SATA 3Gb/s connector(s) 2 x CPU Fan connector(s) 3 x Chassis Fan connector(s) 1 x S/PDIF out header(s) 1 x 24-pin EATX Power connector(s) 1 x 8-pin ATX 12V Power connector(s) 1 x Front panel audio connector(s) (AAFP) 1 x System panel(s) 8 x ProbeIt Measurement Points 1 x Power-on button(s) 1 x Reset button(s) 1 x Go Button(s) 1 x mPCIe Combo header(s) |
Aksesori | User's manual I/O Shield 2 x SATA 3Gb/s cable(s) 4 x SATA 6Gb/s cable(s) 1 x SLI bridge(s) 1 x Q-connector(s) (2 in 1) 1 x ROG Connect cable(s) 1 x 12 in 1 ROG Cable Label(s) 1 x ROG Door Hanger(s) |
BIOS | 64Mb UEFI AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.5, ACPI2.0a Multi-Language BIOS |
Kemampuan Manajemen | WfM2.0, DMI2.0, WOL by PME, PXE |
Disc Pendukung | Drivers Sound Blaster X-Fi 2 Utility Kaspersky Anti-Virus DAEMON Tools Pro Standard ROG CPU-Z ASUS AI Suite II ASUS WebStorage ASUS Utilities |
Form Factor | uATX Form Factor 9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm ) |
Catatan | *1: LucidLogix Virtu MVP supports Windows 7 operating systems. *2: PCIe3.0 speed is supported by Intel 3rd generation Core Processors. *3: The mPCIe 2.0 x1 slot is located on mPCIe Combo expansion card. *4: The mSATA 3Gb/s slot is located on mPCIe Combo expansion card. *5: Supports on Intel Core processor family with Windows 7 operating systems. *6: These SATA ports are for data hard drives only. |
